Allen & Heath ZED-420 16-Channel Mixing Console with USB

Name: Allen &amp; Heath ZED-420 16-Channel Mixing Console with USB
Brand: Allen &amp; Heath
SKU: ZED2042
Availability: InStock

AED 6200.95

The ZED-420 mixer is designed for bands, houses of worship, theatres, and AV applications, featuring 16 mic/line inputs, 2 dual stereo inputs, a 4-band EQ with MusiQ, 4 sub-groups, 6 auxiliary sends, and a 7×2 matrix. The mixer includes configurable USB audio in/out for easy stereo recordings and uses DuoPre pre-amps to provide a wide 69dB gain range with low noise, ideal for professional PA setups and sound reinforcement applications.

In stock

Estimated Delivery : Up to 3 business days
Free Shipping & Returns : On all orders over AED 1000

Guaranteed Safe And Secure Checkout

ZED-420 Audio Mixer

The ZED-420 is the perfect choice for bands, houses of worship, theatres, and AV applications. Designed with a comprehensive professional feature set, this mixer seamlessly integrates into any sound reinforcement system. It offers a robust suite of controls and inputs, ready to elevate your audio experience with clarity and precision.

Key Features

Specification	Details
Inputs	16 mic/line inputs, 2 dual stereo inputs
EQ	4-band EQ with MusiQ
Sub-Groups	4 sub-groups
Auxiliary Sends	6 auxiliary sends
Matrix	7×2 matrix
Mic Pre-Amps	DuoPre design with 69dB gain range
Mute	Illuminated mute buttons
Faders	ALPS 100mm faders
Connectivity	Neutrik XLR and 1/4 inch jacks
USB Audio	Configurable USB stereo audio in/out
Phantom Power	Individual channel 48V phantom power
Direct Outputs	Available on each mono channel
Metering	12 bar meters with peak signal indicators
Main Mix Outputs	L, R, and M outputs
