BSS BLU-100 Audio Signal Processor 12×8 with BLU Link
The BSS Audio Soundweb London BLU-100 12×8 Signal Processor is a networked audio routing DSP processor with 12 inputs, 8 outputs, configurable signal processing, and a 48-channel digital audio bus. It supports full configuration via HiQnet London Architect and offers a low-latency, fault-tolerant connection using standard Category 5e cabling up to 100 yards, extendable to over 24 miles with fiber media converters.
In stock
- Estimated Delivery : Up to 3 business days
- Free Shipping & Returns : On all orders over AED 1000
BSS Audio Soundweb London BLU-100 12×8 Signal Processor with BLU Link
The BSS Audio Soundweb London BLU-100 12×8 Signal Processor with BLU Link is an advanced DSP processor designed for efficient networked audio routing applications. With a fixed configuration of 12 inputs and 8 outputs, it offers configurable signal processing and a high bandwidth, fault-tolerant digital audio bus.
Key Features
- 12 analog inputs with +48V phantom power per channel
- 8 analog outputs
- Versatile signal processing capabilities
- 48-channel low-latency digital audio bus
- Clear front-panel LED indicators for easy monitoring
- Bidirectional locate functionality simplifying device management
- Control inputs and logic outputs for GPIO integration
- Comprehensive Soundweb London interface kit for third-party integration
- Full configuration and monitoring via HiQnet London Architect
Specifications
| Specification | Details |
|---|---|
| Indicators | Signal Present, CLIP, 48 V (Input Only); COM, STAT, ERR, PWR |
| Analog Input | 12 x Electronically Balanced on Phoenix Combicon Removable Screw Connectors |
| Input Impedance | 3.5 Kilohms |
| Maximum Input Level | +20 dBu with 0 dB Input Gain |
| Analog Outputs | 8 x Electronically Balanced on Phoenix/Combicon Removable Screw Connectors |
| Maximum Output Level | +19 dBu |
| Frequency Response | 20 Hz to 20 kHz (+0.5 dB / -1 dB) |
| THD | < 0.01% 20 Hz to 20 kHz, +10 dBu Output |
| Dynamic Range | 108 dB Typical, 22 Hz to 22 kHz, Unweighted |
| Control Ports | 12 Inputs and 6 Outputs |
| Input Voltage | 0 to 4.5 V |
| Output Voltage | 0 or +5 V Unloaded |
| Control Network | RJ45 Ethernet Connector |
| Maximum Cable Length | 300′ / 100 m on Cat 5e Cable |
| Power Consumption | < 55 VA |
| BTU | < 188 BTU/Hour |
| Dimensions | 1.75 x 19 x 9″ / 45 x 483 x 229 mm |
| Weight | 6.4 lb / 2.9 kg |
| Brand | |
|---|---|
| EAN |
