Electro-Voice EKX-15 15-Inch 400W 2-Way Full Range Speaker

Name: Electro-Voice EKX-15 15-Inch 400W 2-Way Full Range Speaker
Brand: Electro-Voice
SKU: EKX-15
Availability: InStock

AED 3620

The Electro-Voice 15” 2-Way Passive Loudspeaker delivers a peak output of 1600W and a peak SPL of 132 dB, utilizing high-sensitivity transducers and SST waveguide technology for precise coverage. Features include eight M10 threaded mounting points, aluminum pole mounts, and metal handles.

In stock

Estimated Delivery : Up to 3 business days
Free Shipping & Returns : On all orders over AED 1000

Guaranteed Safe And Secure Checkout

Electro-Voice 15” 2-Way Passive Loudspeaker

The Electro-Voice 15” 2-Way Passive Loudspeaker is designed for superior sound reinforcement, delivering a peak output of 1600W and an impressive peak SPL of 132 dB. The high-sensitivity transducers, combined with the SST (Signal Synchronized Transducers) waveguide design, ensure accurate and consistent coverage. This loudspeaker is well-suited for a variety of venues and applications thanks to its robust construction and versatile mounting options.

Key Features

This versatile loudspeaker includes:

1600W maximum peak output with 132 dB peak SPL
SST waveguide design for consistent coverage
Lightweight and compact 15mm wood enclosure with EVCoat finish
90 x 60° pattern ideal for mid-size stage coverage
40° monitor angle with rubber feet
Eight M10 threaded mounting points
Durable all-metal handles and aluminum pole mounts

Specifications

Specification	Details
Axial Sensitivity	96 dB full space measurement (SPL, 1 W @ 3.28′ / 1 m)
Maximum SPL	132 dB at 3.28′ (1 m) using broadband pink noise at rated peak power rating
Nominal Impedance	8 Ohms
Power Handling	Continuous / Peak: 400 W / 1600 W
Frequency Response	At -3 dB: 75 Hz to 18 kHz full space measurement At -10 dB: 50 Hz to 20 kHz full space measurement
Recommended High-Pass Frequency	50 Hz
Coverage	Nominal -6 dB: 90 / 60° (H / V) HF: DH-1M 1″ (25.4 mm) titanium compression driver
Transducer	LF: EVS-15M 15″ (381 mm)
Crossover Frequency	1.6 kHz
Minimum Impedance	7.2 Ohms
Connector Type	Dual NL4
Enclosure Material	0.59″ (15 mm), plywood with EVCoat
Grille	18 AWG steel with powder coat
Suspension	8 x M10 threaded mounting points
Dimensions (H x W x D)	26.97 x 17.01 x 16.89″ (685 x 432 x 429 mm)
Weight	51.15 lb (23.2 kg)
