Toa A-3548D 480W Mixer Amplifier with Euro AC Plug

Name: Toa A-3548D 480W Mixer Amplifier with Euro AC Plug
Brand: Toa
SKU: A-3548D 1CEE00
Availability: InStock

AED 4385

The A-3548D is a 480-watt Class D mixer/amplifier featuring emergency and priority paging, three MIC/LINE inputs, one MIC input, and one AUX input suitable for music sources. It includes 2-channel speaker zone selectors, making it ideal for paging announcements and background music in retail shops, schools, offices, and production facilities.

In stock

Estimated Delivery : Up to 3 business days
Free Shipping & Returns : On all orders over AED 1000

Guaranteed Safe And Secure Checkout

A-3548D Class D Mixer/Amplifier

The A-3548D is a versatile class D mixer/amplifier engineered for clear and efficient audio output, delivering up to 480 watts of power. This device is equipped with emergency and priority paging features, making it suitable for announcements and background music in various environments ranging from retail shops to educational institutions and offices.

Key Features

480 W Class D mixer amplifier for both high and low impedance speakers
5 Inputs: 1 Mic, 1 AUX, and 3 x MIC/AUX (selectable) with 2 Phantom power options
2 Zone speaker selectors (high impedance only)
Comprehensive output options: 2 Line out, 1 Rec out
1 Emergency output

Specifications

Power source	100 – 240 V AC, 50 / 60 Hz
Rated output	480 W
Frequency response	50 Hz – 20 kHz (±3 dB (1/8 rated output))
Distortion	≤ 1 % (at 1 kHz, rated power)
Power consumption	601 W (at rated output), 113 W (EN62368-1)
Speaker output	Direct, zones 1 & 2
Amplifier	Class D
S ratio	88 dB (A-weighted)
Connectable microphones	3
Inputs	INPUT 1,2: –60 dB* (MIC)/–20 dB(LINE) selectable, 600Ω, electronically-balanced, removable terminal block (3.81 mm, 5 pins)/ø6.3 mm phone jack (2P) INPUT 3: –60 dB, 600Ω, electronically-balanced, ø6.3 mm phone jack INPUT 4: –60 dB* (MIC)/–20 dB(LINE) selectable, 600Ω, electronically-balanced, ø6.3 mm phone jack (2P) INPUT 5: –20 dB, 10 kΩ, unbalanced, RCA pin jack x 2 PWR AMP:IN: 0 dB*, 600Ω, unbalanced, RCA pin jack
Control input	2 channels, no-voltage make contact input, open voltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 5 pins) ZONE control: No-voltage make contact input, open voltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 4 pins)
Outputs	REC, LINE 1/1: 0 dBV, 600 ohms, unbalanced, RCA pin jack SPEAKER direct, zones 1 and 2: 4-16 ohms in total or 100 V
Control output	Power remote, emergency, zone control: Open collector output, withstand voltage: 30 V DC or less, control current: 25 mA or less, removable terminal block (3.50 mm, 4 pins)
Operating humidity	85% RH or less (no condensation)
Operating temperature	–10 to +40 °C
Finish	ABS resin, Steel plate, paint, black
Dimensions	420 x 96 x 313 mm (W x H x D)
Weight	5.1 kg
